Sheet Metal Fabrication
Sheet Metal Fabrication

Sheet Metal Fabrication

Upload your CAD and DXF files to get an instant quote on sheet metal cutting and bending service for prototypes and production parts. Lead times as fast as 3 days.

All Uploads are confidential and secure

What is Sheet Metal Fabrication?

Sheet metal fabrication is a manufacturing process that uses cutting and bending parts from thin metal sheets. Mechanical Engineers often choose sheet metal parts for their durability and ease of manufacturing. JawsTec’s fabrication and production services offer quick online quotes with a range of sheet metal materials, including aluminum, copper, steel, and stainless steel. With JawsTec’s high accuracy of sheet metal fabrication, and materials range with partners we should be able to do most sheet metal jobs in our Machine Shop. Sheet metal applications include aerospace, defense, automotive, energy, industrial, medical, dental, and consumer products.

Digital Manufacturing - Laser Cutting

Sheet Metal Cutting Processes

  • Laser Cutting Service: Uses a high-power laser beam to cut a material sheet.
  • Waterjet Cutting Service: Uses high-pressure water to cut a material sheet.
holes in metal sheet rework

Sheet Metal Materials

  •  Aluminum
  •  Stainless Steel
  •  Steel
  •  Galvanized Steel
holes in metal sheet rework

Sheet Metal Finishes

Applications and Advantages of Sheet Metal Fabrication:

Fast, Instant Online Quote

Rapid Tooling

Quick Prototypes

Lead times starting at 3 days

No minimum order quantities

Volume-based discounts



Free Instant Quote

1. Upload Files (Up to 30 at a time)

2. Select Material, Color, Finish, and Quantity

3. Add to order, select shipping, expedite, & purchase

Sheet Metal Design Guidelines and Tolerances

Minimum Bend: 1 Times Sheet Metal Thickness
Minimum Hole to Edge Distance: 2 Times Sheet Metal Thickness
Minimum Hole to Hole Distance: 6 Times Sheet Metal Thickness
Minimum Bend Edge to Hole Distance: 6 Times Sheet Metal Thickness
Minimum Feature to Countersink Distance: 8 Times Sheet Metal Thickness
Minimum Countersink Depth: 1 Times Sheet Metal Thickness
Relief Cuts: 1 Times Sheet Metal Thickness
Cutting Feature: ± .00787’’ (0.2 mm)
Bend Angle: ± 1.0°
Bend to Edge: +/- 0.010” (0.254mm)
